Pharma Test Tapped Density and Apparent Density Testing Instrument PT-TD300

The PT-TD300 is used to test the tapped (or “tamped”) density and apparent density of powders, granules, pigments and similar products in compliance with the current USP <616> methods 1 and methods 2 as well as with EP <2.9.34>, DIN EN ISO 787-11 and ASTM B527.
The instrument automatically calculates the tapped density, Hausner flowability ratio and Carr compressibility index after each test and documents the results via the integrated protocol printer.
  • Use a single instrument to test tapped density and apparent density according to both method 1 and method 2 from USP <616>

  • Automated detection of correct cylinder position according to selected method

  • Integrated protocol printer reduces bench space requirements

  • Detailed result report including calculation of Hausner flowability ratio and Carr compressibility index

  • Evaluation of the results according to Hausner and Carr compressibility indices

  • Determine the sample weight to automatically calculate apparent and tapped density

  • Programmable qualification interval timer reminds the user to perform instrument calibration

  • Dedicated calibration programs including reports for tap number, tap height, tap frequency, weight measurement and timer function

  • Copy methods between instruments by using a common USB flash drive

  • Export test reports as text files
